Panga 22'


Pangas unique ride is due to a pad keel which starts at the stern, roughly 16 inches wide, and tapers to the bow.  This is one of the reasons why it requires so little horsepower for this size boat. The 22 is CE certified for up to 150HP, however it can easily carry up to 8 persons and provide very economical and quick boating with 90HP. The Panga is your all in one solution for inshore and offshore fishing.

High Bow Design

The key features of the Panga 22 design is a high bow of almost 4’6” with a beam of 7’6”, gunwale height of 2’3” at the front and 1’10” at the cockpit.  The high bow and gunwale provide buoyancy and elevation for casting and retrieval of carrying heavy loads and minimizes spray coming on board. She only draws 8 inches and can customize a jack plate to take advantage of its shallow draft.



Superior Self Bailing

The boat is self bailing and its recessed drain design is far superior to most boats and proves it to quickly drain water and easily remove all dirt from the main deck surface.  Everyone hates spending 20 minutes in the corner of a boat trying to exit the dirt, soap, and water from the poorly designed drains. You will not have to worry about that with this design.



Seating and Storage

The raised bow area with large storage hatch below makes for a great casting deck for fishing or if you are just out cruising it becomes a very comfortable sun lounge deck with custom made cushions and fully removable, adjustable height & adjustable angle, fwd facing backrests. Sufficiently recessed fwd and aft seating is an option that many bay boats are lacking, but you will love the perfectly recessed seating options of the Panga which allows for family and friends to safely lounge up forward and back aft while running full speed.  The aft seating has custom cushions and quick release backrest options leaving a clean stern for fishing when removed or for easily storing when not in use.  Underneath the stern seating has storage, battery/bilge pump/live well pump access and a live bait well. Seating also exists on the forward part of the center console with storage underneath.  The helm seat options include stainless rocket launchers or a reversible seat upgrade with individually reversible seats which is a great option for one person to drive while the other watches the kids tubing or the fish biting.  Cooler inserts or other options could be customized.



Custom T Top

All Banks Pangas T-Tops are custom built right here in the Carolinas to the highest quality and strength using heavy duty polished aluminum. All tops are a 100% welded piece. They are custom fit for the boat and console then mounted to both the deck and console in eight locations. It can include hard tops or canvas soft tops with electronics box and welded tabs for anything from led lights to outriggers.  Choose from an array colors for either the soft top or hardtop. They will be pre drilled for running wires so no need to worry about future electronics installations. Hardtops can include molded electronics boxes, speaker pods and led pods with hidden channels for running wiring.  All tops come with 4 rocket launchers and anchor light as standard, but can be customized in just about any way.

Engine Power
Banks Pangas are usually rigged out with a Yamaha or Suzuki 4 stroke with a range of sizes to fit the customers needs.  Hydraulic steering, hydraulic jack plates, and multi function controls with fuel management systems to show off its superior efficiency are common options.  All engines are warrantied through registered yamaha and suzuki dealers and may include specials for up to 6 years.  Best engine ranges for the 22' are 90hp - 150hp.

Navigation Tech

Garmin Charplotter Echomap plus 94sv touch screen 9” with keyed-assist, CHIRP Sonar, CHIRP ClearVu and CHIRP SideVu, detailed Bluechart g3 coastal, wifi, quick draw contours, record and rewind, Panoptix Live Scope ready, NMEA 2000 network ready. View all this data including accepting text messages, emails and even phone calls right on your Echomap plus display with a NMEA network. This with the ability to access and update your charts with ActiveCaptain App, plan and save waypoints and routes between the app and your plotter at home or on board. Even add autopilot and engine data to the networked Garmin display if desired.  Customize your electronics with any size screen or Simrad products.



More options include: custom audio, vhf, power poles, trolling motors, electric windless, 12v and USB charging ports, high pressure wash down pump, retractable shade awnings.

Complete Feature List


  • All composite fiberglass hull built with vacuum infusion technology


  • Non skid deck liner


  • Bilge pump plumbed, installed and wired


  • Live bait well pump plumbed, installed and wired


  • Grab rail 316 stainless steel in fwd bow area


  • Self-bailing cockpit with recessed drains and channels for maximum water draining efficiency


  • 316 Stainless steel through hull fittings


  • Built in navigation lights including all around white light


  • Battery selector switch


  • Raised casting deck fwd and aft with safety recessed seating aft


  • Cleats - 316 stainless steel fwd and aft


  • Drink holders (8)


  • Aft swim ladder with 316 stainless steel support/ telescoping ladder


  • Rod holders-316 stainless steel 4 in gunwale,4- 6 on t-top option, 4 in back rocket launcher seating 316 stainless steel, 4 in rod racks (optional 18 total)


  • Rod, gaff, brush racks port and stbd gunnels


  • High density rub rail with 316 stainless steel insert


  • Seating-aft recessed safety seating including custom cushions throughout


  • Seating-fwd of console and stainless steel seating with backrest for steering station including rod holders.  Option for dual reversible facing seating. Cushions throughout.


  • Seating-fwd recessed safety seating including custom cushions


  • Custom matching adjustable and easily removable back rests


  • Stern eyes-heavy duty 316 stainless steel


  • Storage-aft transom seating storage 3 separate compartments including live bait well.


  • Storage-center console under steering helm as well as storage compartment under fwd console seat


  • Storage-optional electronics box/dry storage mounted in T-top, as well as storage net


  • Storage-fwd bow compartment in raised casting deck


  • Storage-fwd anchor locker w/rode storage


  • High Pressure Wash Down Pump


  • Optional T-top- heavy-duty brushed aluminum with optional fiberglass electronics box, storage net, all around white light, welded spreader light/accessory tabs, pre drilled holes for wiring, 4-6 welded rod holders with outer ones angled for fishing.


  • Steering Wheel 316 stainless steel w/knob


  • Scratch resistant windshield


  • Jack Plate- Optional

SPECIFICATIONS

22'

7'6"

4'7"

8"

1680 lbs

8

60 - 150hp

35 gallons

208 miles

Length

Width

Depth

Draft

Weight dry

Persons Capacity

Engine Applicable

Fuel Capacity

Range (115hp)

Top Speed (115hp)

37 mph (2 persons, 20 gallons)

Efficiency (115hp)

6.6 mpg/24mph (2 person,20 gal)

6.2 mpg/26mph (2 person,20 gal)

5.8 mpg/29mph (2 person,20 gal)

*Available inventory and options may change

Customize your Panga how you like with bigger console, toilet, live bait wells, faux teak flooring, accessories etc.

20210215_135012 (1).jpg

Get started with your build Request a quote!

arrow&v
arrow&v
Level of Customization:

Your request for quote has been submitted. We're excited to follow up with you regarding your build.


RIDE DRY. GO ANYWHERE. BE EFishiENT.

®

Learn More About

If you would like to have the shallow draft of your bay boat and skiff yet add more of the offshore capability of a deeper V, than the Panga is the all in one choice.  Is your wallet as efficient as your Panga? Buy one and it will be. Contact Banks Panga today to discuss your build or inquire about inventory. Call us directly at 252.228.9825 or Submit a Request.
